CP Smart App Rack 1000VA UPS

CP Smart App Rack 1000VA UPS

Low stock: 3 left

SKU:OR1000ERM1U

Regular price $651.30
Regular price $829.00 Sale price $651.30
Sale Sold out
Taxes included. Shipping calculated at checkout.
Quantity

CP Smart App Rack 1000VA UPS

{/{Features/Specification (HTML)}}:

Specifications:



  • Phase: Single Phase

  • Form Factor: Rackmount

  • UPS Topology: Line-interactive

  • Energy Saving Technology: GreenPower UPS Bypass Technology

  • Nominal Input Voltage ( Vac ): 230

  • Input Voltage Range ( Vac ): 165 - 271

  • Adjustable Voltage Range ( Vac ): 253 - 271 Vac | 189 - 207 Vac

  • Input Frequency ( Hz ): 50 �� 3 | 60 �� 3

  • Input Frequency Detection: Auto-sensing

  • Rated Input Current ( A ): 10

  • Input Connector Type: IEC C14

  • Detachable Power Cord Plug Type: IEC C14 x 1

  • Power Cord Length: 1.83m

  • Capacity (VA): 1000

  • Capacity (Watts): 600

  • On Battery Waveform: Simulated Sine Wave

  • On Battery Voltage(s) ( Vac ): 230 �� 10 %

  • On Battery Frequency ( Hz ): 50 �� 10% | 60 �� 10%

  • Power Factor: 0.6

  • Automatic Voltage Regulation (AVR): Single Boost

  • Overload Protection: Internal Current Limiting | Circuit Breaker

  • Outlet(s) - Total: 6

  • Outlet Type: IEC C13 x 6

  • Outlet(s) - Battery & Surge Protected: 4

  • Outlet(s) - Surge-Only Protected: 2

  • Typical Transfer Time ( ms ): 4

  • Runtime at Half Load ( min ): 14

  • Runtime at Full Load ( min ): 3.5

  • Typical Recharge Time ( Hours ): 8

  • Start On Battery: Yes

  • User-replaceable: Yes

  • Hot-swappable: Yes

  • Replacement Battery Pack (RBP): RBP0025

  • Replacement Battery Pack (RBP) Quantity ( pcs ): 1

  • Surge Suppression ( Joules ): 810

  • EMI/RFI Filtration: Yes

  • Phone/Network Protection RJ11/RJ45 (Combo): 1-in | 1-out

  • LCD Information Display: Operation Type | Power Status | Battery Status | Load Status | Other Information

  • LCD Setting & Control: Mode Setting | Alarm Setting | Input & Output

  • LED Indicators: Power On

  • HID Compliant USB Port(s): 1

  • Serial Port: Dry Contact

  • Audible Alarms: Battery Mode | Low Battery | Overload | UPS Fault

  • Management Cable ( pcs ): Power Cord x4 | USB Cable x1

  • SNMP/HTTP Remote Monitoring: Yes - with optional RMCARD205

  • Enclosure Construction: Metal

  • Rackmount Ears: Yes

  • Dimensions: 433 x 44 x 389mm

  • Weight: 13.7kg

  • Installed Rack Height ( U ): 1

  • Online Thermal Dissipation ( BTU/hr ): 24

  • Certifications: CE | EAC | RCM | RoHS

  • Warranty: 2 Years



Features:



  • Line-interactive UPS Topology

  • Simulated Sine Wave Output

  • Overload Protection

  • Surge and Spike Protection

  • Phone/Fax/Modem/DSL/Network Protection

  • USB Connectivity Port

  • SNMP/HTTP Remote Management Capability (Optional)

  • Energy Saving Technology

  • Automatic Voltage Regulation (AVR)

  • Hot-swappable Batteries

  • EMI and RFI Filtration

  • LCD Status Display

  • PowerPanel Management Software



What's in the box?



  • 1 x OR1000ERM1U UPS

  • 1 x Rackmount Ears

  • 1 x Power Cord

  • 1 x USB Cable

  • 1 x User Manual
